RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION huel00esp_20230725.log
STATUS IN EPN included since 09-09-2007
LAST AVAILABLE DATA 25-09-2023
LAST RECEIVER LEICA GR50 (25-07-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA LEIAR20/LEIM (21-10-2022 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR20/LEIM (SN: 24238028) from 2022-10-21 to now :
DATA ROUTINELY ANALYSED BY BEK, IGE, MUT, RGA
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 003/2020 N/A
BKGE 335/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 262/2023 78.57%
BEV 268/2023 100%
BKGE 268/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 336/2020 (S) N/A 0%
BKGE 336/2020 (S) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 269/2023 (K) 88.1% 65.48%
BKGE 269/2023 (K) 88.69% 66.07%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

HUEL00ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/09/25 20:37 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2023/09/25 20:37 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/09/25 18:27 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2023/09/25 23:33 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.70.040) wrt site log (4.70/7.813)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
