RESPONSIBLE FOR METADATA GOP (Geodetic Observatory Pecny, RIGTC)
RESPONSIBLE AGENCY RIGTC GOP (Research Institute of Geodesy, Topography and Cartography Geodetic Observatory Pecny)
CURRENT STATION CONFIGURATION tubo00cze_20220502.log
STATUS IN EPN included since 23-09-2001
LAST AVAILABLE DATA 04-10-2022
LAST RECEIVER LEICA GR30 (02-05-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA LEIAR25.R4 LEIT (12-12-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 10401005) from 2011-12-12 to now :
  • LEIAT504/LEIS (SN: 102923) from 2005-12-15 to 2011-12-12 :
DATA ROUTINELY ANALYSED BY BEV, RGA, SGO, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 16-03-2022.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 074/2022 N/A
BEV 074/2022 N/A
BKGE 074/2022 N/A
RINEX V3.03 - GPS+GLO+GAL+BDS+QZSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2022 78.57%
BEV 277/2022 100%
BKGE 277/2022 100%
Hourly
Data centres Online Last data Availability Latency
BEV 075/2022 (A) N/A 0%
BKGE 075/2022 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 278/2022 (N) 100% 98.81%
BKGE 278/2022 (N) 100% 97.62%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

TUBO00CZE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)

    2022/10/05 01:25 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2022/10/05 01:25 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/04 23:39 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2022/10/04 23:39 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/05 04:45 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)

    2022/10/05 04:45 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2022/10/05 04:45 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.52.518) wrt site log (4.52/7.111)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
