EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE FOR METADATA	(Institut National de l'Information Géographique et Forestière)
RESPONSIBLE AGENCY	(Institut National de l'Information Géographique et Forestière)
CURRENT STATION CONFIGURATION	brst00fra_20211124.log
STATUS IN EPN	included since 06-12-1998
LAST AVAILABLE DATA	28-09-2022
LAST RECEIVER	TRIMBLE ALLOY (30-09-2020 to now)
SET TO TRACK	GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA	TRM57971.00 NONE (19-04-2012 to now)
INDIVIDUAL CALIBRATION(S)	none
DATA ROUTINELY ANALYSED BY	BKG, IGN, ROB, SUT, UPA
INCLUSION IN OTHER NETWORK(S)	IGS, EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 28-03-2022.

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BRST00FRA0 :

ASI (broadcaster, registration) - RTCM 3.1 : GPS+GLO
2022/09/27 18:00 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)
2022/09/27 18:00 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)
2022/09/27 18:00 RTCM 3.1/1006: Incorrect Antenna Height in stream (2.0430 m) wrt site log (2.0431 m)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)
2022/09/28 15:42 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)
2022/09/28 15:42 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)
2022/09/28 15:42 RTCM 3.2/1006: Incorrect Antenna Height in stream (2.0430 m) wrt site log (2.0431 m)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)
2022/09/26 20:45 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)
2022/09/26 20:45 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)
2022/09/26 20:45 RTCM 3.2/1006: Incorrect Antenna Height in stream (2.0430 m) wrt site log (2.0431 m)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station BRST00FRA
Last ETRF2000 position valid from 303/2011 to 106/2022 expressed at epoch 001/2010
X = 4231162.792 m	Vx = -0.0011 m/y
Y = -332746.919 m	Vy = -0.0003 m/y
Z = 4745130.691 m	Vz = -0.0008 m/y
