EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	ZU (Land Survey Office)
RESPONSIBLE FOR METADATA	ZU (Land Survey Office)
CURRENT STATION CONFIGURATION	ctab00cze_20250218.log
STATUS IN EPN	included since 21-03-2010
DATA LICENSE	CC-BY-4.0
LAST AVAILABLE DATA	29-03-2025
LAST RECEIVER	LEICA GR30 (17-02-2025 to now)
SET TO TRACK	GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA	LEIAR25.R4/LEIT (13-09-2011 to now)
INDIVIDUAL CALIBRATION(S)	LEIAR25.R4/LEIT (SN: 10471002) from 2011-09-13 to now : GEO - ROBOT (freq: G01, G02, R01, R02, date: 2011-03-04)
DATA ROUTINELY ANALYSED BY	BEV, MUT, RGA, SUT, WUT
INCLUSION IN OTHER NETWORK(S)	EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 02-08-2022.

No recent data available

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

CTAB00CZE0 :

ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)
2025/03/29 11:47 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2025/03/29 11:47 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)
2025/03/29 11:47 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.82) wrt site log (4.82/7.900)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM5)
2025/03/29 08:33 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2025/03/29 08:33 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.82) wrt site log (4.82/7.900)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)
2025/03/29 09:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2025/03/29 09:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)
2025/03/29 09:56 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.82) wrt site log (4.82/7.900)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station CTAB00CZE
Last ETRF2000 position valid from 029/2017 to 316/2022 expressed at epoch 001/2010
X = 4022510.298 m	Vx = -0.0004 m/y
Y = 1053801.608 m	Vy = -0.0002 m/y
Z = 4820712.215 m	Vz = -0.0007 m/y
