RESPONSIBLE AGENCY BMEDGS (Budapest University of Technology and Economics)
RESPONSIBLE FOR METADATA BMEDGS (Budapest University of Technology and Economics)
CURRENT STATION CONFIGURATION bute00hun_20240723.log
STATUS IN EPN included since 31-10-2004
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 03-10-2024
LAST RECEIVER LEICA GR50 (13-10-2021 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R4/LEIT (04-11-2013 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R4/LEIT (SN: 725335) from 2013-11-04 to now :
  • TRM55971.00/TZGD (SN: 30436720) from 2007-07-31 to 2013-11-04 :
DATA ROUTINELY ANALYSED BY BEV, BKG, RGA, SGO, SUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 15-04-2021.

RINEX V2.11 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 105/2021 N/A
BEV 105/2021 N/A
BKGE 056/2021 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2024 78.57%
BEV 277/2024 100%
BKGE 277/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 278/2024 (O) 99.4% 97.62%
BKGE 278/2024 (N) 99.4% 70.83%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

BUTE00HUN0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5) : stream temporarily unavailable

    2024/09/30 18:16 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/09/30 18:16 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/09/30 18:16 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

    2024/09/30 18:16 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5) : stream temporarily unavailable

    2024/09/30 15:51 RTCM 3.2 : Unable to decode the stream

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5) : stream temporarily unavailable

    2024/09/30 21:03 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2024/09/30 21:03 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

    2024/09/30 21:03 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
