RESPONSIBLE FOR METADATA (Institut National de l'Information Géographique et Forestière)
RESPONSIBLE AGENCY (Institut National de l'Information Géographique et Forestière)
CURRENT STATION CONFIGURATION grac00fra_20220211.log
STATUS IN EPN included since 08-11-2015
LAST AVAILABLE DATA 04-10-2022
LAST RECEIVER LEICA GR50 (11-02-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA TRM57971.00 NONE (10-03-2015 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEV, IGE, LPT
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 28-03-2022.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 086/2022 N/A
BEV 086/2022 N/A
BKGI 083/2022 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2022 78.57%
BEV 277/2022 100%
BKGI 277/2022 100%
Hourly
Data centres Online Last data Availability Latency
BEV 087/2022 (A) N/A 0%
BKGI 083/2022 (X) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 278/2022 (N) 100% 100%
BKGI 278/2022 (N) 100% 99.4%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

GRAC00FRA0 :

  • ASI (broadcaster, registration) - RTCM 3.1 : GPS+GLO

    2022/10/04 20:00 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 20:00 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.51.489) wrt site log (4.51)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)

    2022/10/04 17:48 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 17:48 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.51.489) wrt site log (4.51)

  • ROB (broadcaster, registration) - RTCM 3.1 : GPS+GLO

    2022/10/04 22:55 RTCM 3.1 : Unexpected constellations in stream (GPS+GLO) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 22:55 RTCM 3.1/1033: Incorrect Receiver Firmware Version in stream (4.51.489) wrt site log (4.51)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
