EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	DUT (Delft University of Technology)
RESPONSIBLE FOR METADATA	DUT (Delft University of Technology)
CURRENT STATION CONFIGURATION	dlf100nld_20230425.log
STATUS IN EPN	included since 27-09-2015
DATA LICENSE	CC-BY-4.0
LAST AVAILABLE DATA	20-11-2024
LAST RECEIVER	TRIMBLE ALLOY (24-04-2023 to now)
SET TO TRACK	GPS+GLO+GAL+BDS+QZSS+SBAS
LAST ANTENNA	LEIAR25.R3/LEIT (15-04-2011 to now)
INDIVIDUAL CALIBRATION(S)	LEIAR25.R3/LEIT (SN: 10030006) from 2011-04-15 to now : GEO - ROBOT (freq: G01, G02, date: 2010-04-26)
DATA ROUTINELY ANALYSED BY	BKG, GFZ, LPT, ROB
INCLUSION IN OTHER NETWORK(S)	IGS, EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 01-03-2022.

No recent data available

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

DLF100NLD0 :

ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM7)
2024/11/20 11:59 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/11/20 11:59 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO+GAL+BDS+QZSS)
2024/11/20 11:59 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)
2024/11/20 11:59 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0000 m)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM7)
2024/11/21 08:44 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/11/21 08:44 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt source table (GPS+GLO+GAL+BDS)
2024/11/21 08:44 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)
2024/11/21 08:44 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0000 m)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM7)
2024/11/21 10:03 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/11/21 10:03 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (6.20,31/JAN/2023) wrt site log (6.20)
2024/11/21 10:03 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.0000 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station DLF100NLD
Last ETRF2000 position valid from 270/2015 to 316/2022 expressed at epoch 001/2010
X = 3924698.113 m	Vx = -0.0007 m/y
Y = 301124.802 m	Vy = -0.0000 m/y
Z = 5001904.995 m	Vz = -0.0015 m/y
