RESPONSIBLE FOR METADATA DUT (Delft University of Technology)
RESPONSIBLE AGENCY KAD (Kadaster)
CURRENT STATION CONFIGURATION kos100nld_20201220.log
STATUS IN EPN included since 17-04-2016
LAST AVAILABLE DATA 29-09-2022
LAST RECEIVER SEPT POLARX5E (21-09-2020 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA LEIAR25.R3 LEIT (23-05-2013 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 10050009) from 2013-05-23 to now :
DATA ROUTINELY ANALYSED BY BKG, LPT, ROB
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 15-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 105/2020 N/A
BEV 001/2020 N/A
BKGI 105/2020 N/A
RINEX V3.05 - GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 266/2022 78.57%
BEV 272/2022 100%
BKGI 272/2022 100%
Hourly
Data centres Online Last data Availability Latency
BEV 106/2020 (A) N/A 0%
BKGI 106/2020 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 273/2022 (U) 100% 100%
BKGI 273/2022 (U) 100% 99.4%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

KOS100NLD0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2022/09/30 21:06 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS+SBAS) wrt source table (GPS+GLO+GAL+BDS+QZSS)

    2022/09/30 21:06 RTCM 3.3/1033: Incorrect Receiver type in stream (SEPT) wrt site log (SEPT POLARX5E)

  • BKG (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2022/09/30 19:06 RTCM 3.3/1033: Incorrect Receiver type in stream (SEPT) wrt site log (SEPT POLARX5E)

  • ROB (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+QZSS+SBAS (MSM7)

    2022/09/30 00:09 RTCM 3.3/1033: Incorrect Receiver type in stream (SEPT) wrt site log (SEPT POLARX5E)

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
