RESPONSIBLE AGENCY ELB (Estonian Land Board)
RESPONSIBLE FOR METADATA ELB (Estonian Land Board)
CURRENT STATION CONFIGURATION kure00est_20240621.log
STATUS IN EPN included since 27-04-2008
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-EUREF-KURE00EST
LAST AVAILABLE DATA 03-10-2024
LAST RECEIVER LEICA GR50 (20-06-2024 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA LEIAR25.R4/LEIT (19-02-2018 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY BKG, NKG, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 14-04-2020.

RINEX V2.11 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 105/2020 N/A
BEV 023/2020 N/A
BKGE 105/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2024 78.57%
BEV 277/2024 100%
BKGE 277/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 278/2024 (M) 100% 0%
BKGE 278/2024 (M) 100% 24.4%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

KURE00EST0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/10/03 21:31 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt site log (GPS+GLO+GAL+BDS)

    2024/10/03 21:31 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2024/10/03 21:31 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80) wrt site log (4.80/7.900)

    2024/10/03 21:31 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

    2024/10/03 21:31 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0526 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/10/03 19:28 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt site log (GPS+GLO+GAL+BDS)

    2024/10/03 19:28 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80) wrt site log (4.80/7.900)

    2024/10/03 19:28 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

    2024/10/03 19:28 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0526 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM5)

    2024/10/04 05:31 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt site log (GPS+GLO+GAL+BDS)

    2024/10/04 05:31 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.80) wrt site log (4.80/7.900)

    2024/10/04 05:31 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.15897 m)

    2024/10/04 05:31 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.0526 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
