RESPONSIBLE FOR METADATA LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
RESPONSIBLE AGENCY LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
CURRENT STATION CONFIGURATION mar700swe_20210210.log
STATUS IN EPN included since 31-01-2016
LAST AVAILABLE DATA 04-10-2022
LAST RECEIVER TRIMBLE ALLOY (17-06-2020 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R3 LEIT (27-04-2011 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 09040009) from 2011-04-27 to now :
DATA ROUTINELY ANALYSED BY BEV, BKG, NKG, WUT
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 28-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 118/2020 N/A
BEV 001/2020 N/A
BKGI 118/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2022 78.57%
BEV 277/2022 100%
BKGI 277/2022 100%
Hourly
Data centres Online Last data Availability Latency
BEV 119/2020 (A) N/A 0%
BKGI 119/2020 (A) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 278/2022 (O) 99.4% 99.4%
BKGI 278/2022 (O) 100% 96.43%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

MAR700SWE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/04 21:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 21:56 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2022/10/04 21:56 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2022/10/04 21:56 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1705 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/04 19:53 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 19:53 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2022/10/04 19:53 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2022/10/04 19:53 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1705 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/05 01:01 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/05 01:01 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (5.45,06/MAR/2020) wrt site log (5.45)

    2022/10/05 01:01 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0001 m) wrt site log (0.003 m)

    2022/10/05 01:01 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1705 m) exceeds threshold

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/
