RESPONSIBLE AGENCY CNES (Centre National d'Etudes Spatiales)
RESPONSIBLE FOR METADATA CNES (Centre National d'Etudes Spatiales)
CURRENT STATION CONFIGURATION metg00fin_20221201.log
STATUS IN EPN included since 13-05-2018
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 03-10-2024
LAST RECEIVER SEPT POLARX5 (01-12-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+IRNSS+SBAS
LAST ANTENNA TRM59800.00/SCIS (01-09-2022 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY BEV, BKG, NKG, ROB
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 06-08-2020.

RINEX V2.11 - GPS+GLO+GAL+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 218/2020 N/A
BEV 023/2020 N/A
BKGI 218/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+IRNSS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2024 78.57%
BEV 277/2024 100%
BKGI 277/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 278/2024 (O) 100% 100%
BKGI 278/2024 (N) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

METG00FIN0 :

  • ASI (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+SBAS (MSM7)

    2024/10/03 22:34 RTCM 3.3 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+SBAS) wrt source table (GPS+GLO+GAL+BDS)

    2024/10/03 22:34 RTCM 3.3/1006: Incorrect Antenna Height in stream (2.0352 m) wrt site log (2.12183 m)

    2024/10/03 22:34 RTCM 3.3/1006: Coordinate difference with ETRS89 ( 2.1210 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+SBAS (MSM7)

    2024/10/03 20:33 RTCM 3.3/1006: Incorrect Antenna Height in stream (2.0352 m) wrt site log (2.12183 m)

    2024/10/03 20:33 RTCM 3.3/1006: Coordinate difference with ETRS89 ( 2.1210 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.3 : GPS+GLO+GAL+BDS+SBAS (MSM7)

    2024/10/04 06:37 RTCM 3.3/1006: Incorrect Antenna Height in stream (2.0352 m) wrt site log (2.12183 m)

    2024/10/04 06:37 RTCM 3.3/1006: Coordinate difference with ETRS89 ( 2.1210 m) exceeds threshold

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/
