RESPONSIBLE FOR METADATA ASGEUPOS (ASG-EUPOS Management Center Head Office of Geodesy and Cartography)
RESPONSIBLE AGENCY GUGiK (Head Office of Geodesy and Cartography)
CURRENT STATION CONFIGURATION redz00pol_20230831.log
STATUS IN EPN included since 08-06-2008
LAST AVAILABLE DATA 25-09-2023
LAST RECEIVER TRIMBLE NETR9 (12-05-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS+QZSS
LAST ANTENNA TRM59900.00/SCIS (07-11-2016 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM55971.00/TZGD (SN: 30436524) from 2007-12-07 to 2014-10-29 :
  • TRM59900.00/SCIS (SN: 5319361156) from 2014-10-29 to 2016-07-04, from 2016-11-07 to now :
DATA ROUTINELY ANALYSED BY BEV, LPT, NKG, SUT, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 13-12-2021.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 346/2021 N/A
BEV 346/2021 N/A
BKGE 346/2021 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+QZSS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 262/2023 78.57%
BEV 268/2023 96.43%
BKGE 268/2023 100%
Hourly
Data centres Online Last data Availability Latency
BEV 342/2021 (L) N/A 0%
BKGE 342/2021 (L) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 269/2023 (L) 100% 100%
BKGE 269/2023 (L) 100% 98.81%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Location

Pictures
