RESPONSIBLE AGENCY IGE (Instituto Geografico Nacional de Espana)
RESPONSIBLE FOR METADATA IGE (Instituto Geografico Nacional de Espana)
CURRENT STATION CONFIGURATION tar000esp_20231024.log
STATUS IN EPN included since 15-09-2019
DATA LICENSE CC-BY-4.0
DIGITAL OBJECT IDENTIFIER (DOI) https://doi.org/10.24414/ROB-EUREF-TAR000ESP
LAST AVAILABLE DATA 07-10-2024
LAST RECEIVER LEICA GR25 (07-04-2021 to now)
SET TO TRACK GPS+GLO+GAL
LAST ANTENNA LEIAR20/LEIM (24-10-2023 to now)
INDIVIDUAL CALIBRATION(S) none
DATA ROUTINELY ANALYSED BY ASI, BEK, IGE, WUT
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 02-12-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 335/2020 N/A
BEV 316/2020 N/A
BKGE 335/2020 N/A
RINEX V3.03 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 275/2024 78.57%
BEV 281/2024 100%
BKGE 281/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 282/2024 (Q) 100% 100%
BKGE 282/2024 (P) 100% 98.81%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

TAR000ESP0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2024/10/07 21:56 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL) wrt source table (GPS+GLO)

    2024/10/07 21:56 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2024/10/06 23:11 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

    2024/10/06 23:11 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0771 m) wrt site log (0.20198 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL (MSM7)

    2024/10/08 14:31 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.11.606) wrt site log (4.11/6.713)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

Location

Pictures
