EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	UNPG (University of Perugia)
RESPONSIBLE FOR METADATA	UNPG (University of Perugia)
CURRENT STATION CONFIGURATION	untr00ita_20201209.log
STATUS IN EPN	included since 04-03-2007
LAST AVAILABLE DATA	19-11-2020 (dormant station)
LAST RECEIVER	TPS NET-G5 (29-11-2020 to now)
SET TO TRACK	GPS+GLO+GAL+BDS
LAST ANTENNA	TPSCR.G5/TPSH (18-12-2018 to now)
INDIVIDUAL CALIBRATION(S)	none
DATA ROUTINELY ANALYSED BY	ASI, BKG, LPT, SGO, UPA
INCLUSION IN OTHER NETWORK(S)	EPOS

Data Provided

No recent data available

No recent data available

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

UNTR00ITA0 :

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station UNTR00ITA
Last ETRF2000 position valid from 311/2016 to 324/2020 expressed at epoch 001/2010
X = 4590764.745 m	Vx = -0.0012 m/y
Y = 1032366.584 m	Vy = -0.0020 m/y
Z = 4291666.243 m	Vz = 0.0005 m/y
